48'-0" Over-all-length
13'-6" Over-all-height
102" Over-all-width
Tandem air ride suspension
Polished aluminum wheels
Low profile 255-70R-22.5 tires
.050 Prepainted white aluminum exterior panels
Extruded aluminum top rail
Special lower steel rail configuration
Electric over hydraulic leveling gear in front with
.....spirit levels
Electric over hydraulic leveling gear between tandem
.....with spirit levels, individual control boxes for each
.....pair of legs
48'-0 Observation deck
Full length fold down hand railing
Front access ladder
3/16 Aluminum tread plate deck full welded
Full length painted steel storage boxes with contour
.....fenders and dress off panels, stainless steel handles,
.....hinges and ICC latches
Doors: One (1) 24 x 78 curbside emergency exit with
.....3-point lock assembly on gooseneck
3/8" Plywood walls
3/4" Plywood subfloor
Insulation: 2" Walls, 3" ceiling foam & 4" fiberglass
.....in floor
INDEX
Expandable Side Wall Specifications
Low friction slide rails with roller assemblies
43" Expansion per side
32'-0 Side wall length
Two (2) hydraulic folding floor assemblies with
.....stainless steel continuous hinge
Automatic 12 VDC floor and expandable sidewall
.....limit switches (Prevent one (1) function being
.....performed prior to another)
Doors: Two (2) 30 x 78 steel with slim line panic bar
.....assemblies and door closures, stairs and handrails
93" Ceiling Height
Full length acoustical drop ceiling
12 Volt & 110 VAC hydraulic power pack with an 11
.....gallon reservoir
4-Button hand held control module
INDEX
Curbside Wall Assembly
Four (4) 24 X 36 fixed dark tinted windows
.....equally spaced
Four (4) one piece horizontal blinds
82" Ceiling height
Horizontal banding grey naugahyde with
.....formica dividers
Three (3) wall stabilizer jacks
INDEX
Roadside Wall Assembly
Full length entertainment center consisting of:
.....Two (2) TV's
CD player, cassette player stereo & two (2) speakers
Full length storage cabinets under entertainment
.....center, with counters at each end
Formica faced cabinets and counters
Carpet entire expandable area
Three (3) stabilizer wall jacks
INDEX
Kitchen Assembly
Custom manufactured overhead storage compartments,
.....top both walls
Custom manufactured full height, full width front
.....wall storage cabinet, with adjustable shelves
21" Deep "U" shaped counter assembly with
.....undercabinet storage between components & center
.....flip-up counter
Large stainless steel sink
Hot & cold water on demand
On demand hot water heater
Under counter ice maker with filter assembly
RV style refrigerator
Cellular phone
Fax machine
Counter mount microwave
Counter mount coffee maker
One-piece linoleum floor
Wallpaper (vinyl) on walls
INDEX
Bathroom Assembly --
Two at rear of trailer consisting of:
Stainless steel toilets
Vanity with ceramic sink
On demand hot and cold water
One-piece linoleum floor
Wall paper (vinyl)
Mirror
Decor light
Exhaust fan
INDEX
Water System
One (1) 300 gallon fresh water holding tank,
.....stainless steel
One (1) 250 gallon grey water holding tank,
.....stainless steel
One (1) 100 gallon black water holding tank,
.....stainless steel
3" PVC discharge valves
Standard garden hose fill
Indicator panel to monitor water levels on grey &
.....fresh water
INDEX
Electrical
Tractor mounted 40 KW diesel with safety
.....shut down package
Self charging system
23'-0" generator - trailer power cord
100'-0 shore power cord to service 30 AMP capacity
.....transfer switch (Automatic)
Twenty (20) convenience plugs
Twenty (20) fluorescent light fixtures
.....with paracube lens
12 Volt battery charger automatic
4 - 6-Volt batteries on slide out tray
Five (5) 12-volt set-up light throughout
INDEX
HAVAC System
Nose mount central heating & cooling system
Bard 49WA3
Central main duct complete with diffusers throughout
Digital thermostat controlled
INDEX
Testing
Tested and full compliance per MIL-S-62472 (AT)
Water tested in three (3) stages per MIL-S-62472 (AT)
INDEX
Painting
Dupont imron black with special mixed red striping
